Description

Octaves is a six band pulse-wave based analog additive oscillator. Pile up multiplications of your frequency to get a lo-fi-retro wall of squared sound! Octaves VCO features six doubled frequency pulses, or octaves, with common PWM and volume control for each of them.

There are six VCAs (one for each pulse) which let you modulate the volume of each octave. This can be done either manually or via CV. When a CV is patched to the Volume INs the manual controls become attenuators. On top of that, Octaves VCO has a multi-mix feature, this means that each octave is summed in cascade to the next one so you can either have one output with all frequencies or break the chain and get several sums and modulate each independently!

Features:

• Six bands, multiple of the base frequency.
• Square wave analog oscillator with Octaves selector PWM control and sync.
• Range control for Tune pot.
• Volume CV control and individual output for each band
• Cascaded summing outputs.

Specs:

• Power Consumption: +12V: 110mA, -12V: 84mA
• Width: 12 HP
• Depth: 22mm, including power connector
• Aluminium, heat-treated front panel
• Designed, kits prepared and completed modules assembled in Barcelona
